Product Details:
|
|
Place of Origin: | CHINA |
---|---|
Brand Name: | GUIBAO |
Certification: | Rohs/ UL |
Model Number: | 890 |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 500ml:2000 pcs |
Price: | Negotiable |
Packaging Details: | 24 pcs per carton |
Delivery Time: | 4 working days |
Payment Terms: | T/T |
Supply Ability: | 20000pcs/4 working days |
Detail Information |
|||
Color: | The Color Is Gray Or According To The User's Needs | Shelf Life: | 12 Months |
---|---|---|---|
Material: | Silicone Sealant | Packing: | 300ml Per Cartridge Or As Required By The Customer |
Key Words: | Electronic Bonding Potting Sealant | Feature: | One Part,Excellent Electrical Insulation Performance And Chemical Stability |
High Light: | Breakdown Resistant Electronic Grade Silicone Sealant,300ml Electronic Grade Silicone Sealant,CE anti corrosion silicone sealant |
Product Description
Electronics Bonding Potting Sealant Fluid or Semi-fluid
Product Feature
Single-component room temperature moisture-curing silicone sealant;
Excellent high temperature and low temperature elasticity after curing;
Excellent electrical insulation performance and chemical stability, resistant to breakdown and corrosion;
Good adhesive sealing, which can effectively prevent the infiltration of water and powder;
Compliance with EU RoHS standards and CE certification.
Application Field
Protection potting of small electronic components;
Protection potting of module;
Protection potting of LED photoelectric display (screen);
Bonding and waterproof sealing of electronic appliances and communication equipment.
Technical Parameters Before and After Curing (not to be considered as a product standard)
No. |
Item |
Typical Technical Indicators |
Test Method |
Before curing |
|||
1 |
Appearance |
Fluid or semi-fluid |
/ |
2 | Density (g/cm3) | 1.25 | GB/T 13477 |
3 | Track free time (min) | 20~30 | |
After curing (after 14 days at 23 ± 2 ° C, humidity 50 ± 5% ) | |||
4 | Appearance | Elastomer Rubber | / |
5 | Hardness (Shore A) | 40 | GB/T 531 |
6 | Tensile strength (MPa) | 1.8 | GB/T 528 |
7 | Elongation at break (%) | 200 | |
8 | Volume resistivity (Ω·cm) | 1.0×1014 | GB/T 1692 |
9 | Breakdown voltage strength (kV/mm) | 18 | GB/T 1695 |
Colour
The color is gray or according to the user's needs.
Packing Specification
Packed in a net capacity of 300ml per cartridge or as required by the customer.
Storage
Store in a cool, dry and ventilated place. The storage period is 12 months from the date of manufacture.
Use Limit
It should not be used in dense and non-ventilated places, not suitable for continuous water immersion, and can not be used as the structural sealant. When the material surface is lower than 4 °C or exceeds 50 °C, it is not suitable for application.
Instructions
Surface treatment
The substrate surface should be dry clean and free from rust, dust and oil, etc.; the cleaning solvents that can be used include isopropyl alcohol and acetone; the majority of the substrate is perfectly bonded except PTFE, polypropylene, polyethylene and similar materials.
Bonding
The sealant is squeezed onto the cleaned surface with a sealant gun to make it evenly distributed; if the potting position is deep, the time for complete curing will be prolonged; if the temperature is lower, the curing time will be prolonged.
Primer
In order to achieve the best bonding effect, it is recommended to apply the special primer from Guibao Company; the surface of the substrate is treated with a solvent, and the primer is dipped, painted or sprayed on the surface of the substrate to form a film; the silicone sealant is
applied to the surface of the substrate; the special application is carried out in three steps of drying, humidification and high temperature drying to ensure the stability of silicone sealant curing.
